WALKIN PETS Large Blue 15 inch strut 16 inch Foam Filled Wheels

．Part Number:

MIX-MCE-WIP-FC7-1516

．Price:

Burgundy
	HKD 4,092.00

．

Availability: In Stock

．Remarks:

．Qty:

Add to cart Direct checkout + Add to wish list

WALKIN PETS Large Blue 15 inch strut 16 inch Foam Filled Wheels

Product Details

Only one measurement required.

Fully adjustable in height, length, and width.

Fits dogs weighing from 51 to 69 pounds (weight determines correct wheelchair frame size).

Wheelchair Frame made of durable, lightweight extruded aluminium.

Dense foam wheels with rubber outer layer; will not puncture, easy to clean, all-terrain.

Easy to resell because it can be adjusted and used on other dogs.

All wheelchair parts are washable; folds flat for easy transport and storage.

Fits med/large breeds: Bulldog, Border Collie, Cocker Spaniel, American Eskimo Dog, Sheepdog, Rottweiler, Cattle Dog, Chow Chow, Collie, Husky, Pitbull, German Shepherd, Labrador Retriever, Boxer, Dalmatian, Doberman, Weimaraner, Rhodesian Ridgeback, Chesapeake Bay Retriever, and more.

Product Specifications
WHAT’S IN THE BOX?

1 Frame

2 Sets of extenders

2 Connectors

1 Front Harness with Sleeves

1 Set Leg Rings Rear Support Saddle

1 Belly Belt

2 Stirrups

1 Instruction Manual

Frame:
The Frame is powder-coated aluminium in blue, pink, or camo. It will not bend, break, or rust. The molded plastic knuckles attach the frame to the legs; 360 degrees of ‘teeth’ hold the knuckle in place. On the side of the knuckle, a spring-loaded turning cap allows you to loosen the knuckle and swivel the legs up or down.

Width Connectors: (2 connectors with regular frame)
The width connector connects the left and right side of the frame together. If the width of your dog is 5- 9.5 inches, you will use the smaller width connector; 9-13.5 inches will need the longer connector.

Length Extenders: (2 extender sets with regular frame)
The adjustable length extenders connect the front harness in place with the wheelchair. There are two different sizes. If the dog is 9-19 inches, the smaller extenders are used. The small extenders will already be attached to the wheelchair. If the animal’s length is 18-25 inches, the larger extenders are needed. Length is determined by back of front leg to back of rear leg.

The Front Harness
The dog’s head goes between the blue and black straps. The red strap goes under the dog’s front legs and clips on the side of the harness. The shoulder pads are made of neoprene and keep the straps and buckles from causing discomfort for the dog. Neoprene comfort sleeves wrap around the straps for the dog’s comfort. Comfort sleeves can be cut in half if they are too long.

Leg Rings:
The dog’s hindquarters are held in place by the leg rings, or our rear harness support system. The leg rings can also be used as a lifting harness when out of the wheelchair; the excess strapping can be touch-fastened together to make handles on each side.

Struts & Foam Wheels:
Depending on your pet’s fold of flank measurement, you will receive a set of wheels attached to struts. Struts snap into the leg of the wheelchair frame and adjust to the height needed. Struts are adjustable within a range of 3 inches and come in 4 different sizes: 6”, 9”, 12”, & 15”. The foam wheels are great for all terrains. They feature a dense foam interior with an outer rubber layer. These wheels will not puncture, they wear extremely well, and are easy to clean. Sizes available: 12″ & 16″.

Belly Belt:
The Belly Belt will help support your dog’s back. It is not always necessary to use the belly belt, but is highly recommended for dogs with a long back, overweight or elderly dogs, dogs with curvature of the spine, and dogs with disc problems.

Stirrups:
Stirrups are used to hold the dog’s legs off the ground so they don’t drag due to paralysis, knuckling under, or foot injuries. The adjustable stirrups are positioned to hold the foot up at the hock. If your dog doesn’t need them, the stirrups may be removed from the wheelchair.

The Manual:
The manual gives instructions and tips on assembling and using the Walkin’ Wheels
Wheelchair.

Tool Kit:
The tool kit comes in a plastic bag and includes and Allen wrench and set screws. The (optional) set screws may be used to tighten up the wheelchair frame and reduce flexibility, depending on your preference.

How to Choose the Right Size
Measure the Rear Leg Height to the toe pad, ideally when your pet is laying down, as shown in the photo. Do not pull the leg tight; leave some natural bend.

Rear Leg Height

14-16″

17-20″

21-22″

23-25″

Apply to
Cat or Dog

WALKIN' PETS

Walkin’ Pets by HandicappedPets.com was created in 2001 by Mark C. Robinson in memory of Mercedes, a slightly epileptic Keeshond who was put to sleep before her time because Mark didn’t know any better and had no way to find out more.

Now there’s a way.

We have all the products you’ll need to care for your ageing, injured, and special needs pets!
